Coconut Oil Processing Plant

Contact Now

Coconut oil refining production line

Quick details

Condition: New

Usage: coconut oil

Type: Coconut oil refining production line

Automatic level: semi-automatic

Voltage: 220V / 380V

Power (W): 7.5 kW

Dimensions (L * W * H): according to hydraulic press capacity

Weight: 1200 kg

Coconut Oil Processing Description

Coconut contains 33% oil. It can be used as a cooking oil. The processing technique is cold press extraction. We offer a complete ramie machine, including pre-treatment equipment, presses, extraction solvents, refiners and more.

First, coconut pretreatment

Before extracting oil from coconut, you need to grind it by washing, crushing, softening, peeling and cooking. For cleaning, we offer magnetic separators, aspirator or cleaning screens of different sizes, as shown below, in order to remove impurities from the coconut.

Then, the temperature and moisture of the coconut flakes are adjusted by adjusting or softening the kettle to make them soft and moist enough to peel off. This step increases its ductility. Below is a photo of the softened kettle.

The peeling roll will be a wet software chip. We have vertical peeling rolls, multi-stage peeling rolls, hydraulic peeling rolls and spring peeling rolls, etc., as shown below.

II coconut oil press

The sheet will be pressed first by the continuous screw press. After pressing, they are divided into two parts: pressing the oil and pressing the cake. The oil and fat in the pressed cake will be further extracted by the solvent.

The main engine of the coconut punching machine

The main engine consists of a base, vertical, top plate, oil drip pan nut, etc., one of its main components. First, the grease material was placed into the boring assembly of the press and then rushed by the cylinder piston. The grease will flow out of the boring gap and then be stored through the oil drop drum.

Hydraulic system of coconut press

The hydraulic system is the main power of the machine, including the drive shaft, steam turbine, worm gear, gear pump, high pressure pump, relief valve; high pressure safety valve; hand operated valve; seamless steel pipe; pipe connection and other SPART parts. This machine uses a word power pack and compares it with two plunger pumps. This is faster, higher pressure and can withstand higher temperatures. It can continue to work when the oil exceeds 65 degrees, but a cooling device is needed.

Coconut press electronic system

The electronic system is an advanced part of the machine, it is fully automatic and easy to operate. There is no special requirement for operation, so this machine is especially suitable for agriculture. It consists of motors, voltmeters, pressure gauges, power fuses and more.

The main technical parameters:

Model 6YY-360

Horizontal hydraulic

Production conditions 1-2 staff, plant 30m3

Capacity 80-120kg / hour

Dimensions (mm) 2800 × 800 × 1500

Working thrust 230T

Motor power 1.5KW

Model 6YL-100 6YL-120 6YL-130 6YL-160

Screw speed 30~40R / min 30~40R / min 28~40R / min 28~40R / min

Dimensions 1950 * 1300 * 1900 * 2050 * 1350 2200 2000 * 1600 * 2150 2500 * 1600 * 2500

Power Y160M-6-7.5KW Y160L-6-11KW Y180L-6-15KW Y200L-6-18.5KW

Vacuum pump Y90S-4-1.1KW Y100L1-4-1.5KW Y100L1-4-2.2KW Y100L1-4-2.2KW

Heater 3KW 3.3KW 3.8KW 4KW

Characteristics of coconut oil refining production line

1. High oil and high yield, low oil residue in the cake: the oil left in the cake is less than 6%. The thickness of the filter cake can be adjusted once the machine is stopped;

2. Compact size: only 10-20m2 is enough.

3. The surface of the high-purity machine is made of chrome-plated stainless steel, which meets food hygiene standards.

4. Easy to operate. You should follow the instructions.

5. Components: screw stamping parts, electrical control system, automatic heating, adjustment mechanism, drive unit and vacuum oil filter.

6. Convenience: The structure is simple, the floor space is small, it is fully enclosed and easy to operate.

Coconut Oil Crude Oil Refining

Crude oil castor oil has many impurities, such as phospholipids, free fatty acids, pigments, waxes, sterols, sands, etc., we must get rid of these impurities to obtain edible oil.

Coconut Oil degumming

There are many ways to move mucus impurities from crude oils and fats, for example, hydration, heating, adding acids, etc. We have hydrated tanks, acid refining mixers, etc., as shown below.

Coconut Oil Deacidification

This step is to remove the pigment from the crude oil to adjust its color. You can adjust to the requirements of your market. We have acid refining tanks.

Coconut Oil deodorant

This step is to move the bad smell from the crude oil. This is an important stop for refined oil. We have deodorized the cans.
